| Part No. |
Frequency MHz |
Flash KB |
RAM KB |
EMMC (SDRAM) |
FPU | I/Os |
Vmin (V) |
Vmax (V) |
GPTMR 16-bit |
Advanced TMR 16-bit |
Basic TMR 16-bit |
SysTick 24-bit |
IWDG | WWDG | RTC |
ADC 12-bit cell |
ADC 12-bit channels |
DAC 12-bit cell |
DAC 12-bit channels |
Analog Comparator |
TSC Channels |
SPI | I2S | I2C | U(S)ART | CAN | SDIO | USBD | CEC | Package |
| APM32S103TBU6 | 96 | 128 | 36 | 0 | 1 | 26 | 2 | 3.6 | 3 | 1 | 0 | 1 | 1 | 1 | 1 | 2 | 10 | 0 | 0 | 0 | 0 | 1 | 0 | 1 | 2 | 2 | 0 | 1 | 0 | QFN36 |
| APM32S103C8T6 | 96 | 64 | 36 | 0 | 1 | 37 | 2 | 3.6 | 3 | 1 | 0 | 1 | 1 | 1 | 1 | 2 | 10 | 0 | 0 | 0 | 0 | 2 | 0 | 2 | 3 | 2 | 0 | 1 | 0 | LQFP48 |
| APM32S103CBT6 | 96 | 128 | 36 | 0 | 1 | 37 | 2 | 3.6 | 3 | 1 | 0 | 1 | 1 | 1 | 1 | 2 | 10 | 0 | 0 | 0 | 0 | 2 | 0 | 2 | 3 | 2 | 0 | 1 | 0 | LQFP48 |
| APM32S103RBT6 | 96 | 128 | 36 | 0 | 1 | 51 | 2 | 3.6 | 3 | 1 | 0 | 1 | 1 | 1 | 1 | 2 | 16 | 0 | 0 | 0 | 0 | 2 | 0 | 2 | 3 | 2 | 0 | 1 | 0 | LQFP64 |
| APM32S103VBT6 | 96 | 128 | 36 | 0 | 1 | 80 | 2 | 3.6 | 3 | 1 | 0 | 1 | 1 | 1 | 1 | 2 | 16 | 0 | 0 | 0 | 0 | 2 | 0 | 2 | 3 | 2 | 0 | 1 | 0 | LQFP100 |
